| 序號 | 零件代號 | 名稱 | 英文名稱 | 是否配件 | 數(shù)量 |
| 1 | 4120706513 | 轉(zhuǎn)向缸HSGL-80*45*370-760 | Steering cylinder hsgl-80*45*370-760 | Y | 2 |
| 2 | 27150109901 | 銷軸 | Axis | Y | 2 |
| 3 | 27150110951 | 銷軸 | Axis | Y | 2 |
| 4 | 4030000280 | O形圈GB3452.1-19.0*2.65G | O-ring gb3452.1-19.0*2.65g | Y | 2 |
| 5 | 27150105312 | 墊圈16 | Washer 16 | Y | 8 |
| 6 | 4015000288 | 墊圈GB1230-12EpZn-45 | Washer gb1230-12epzn-45 | Y | 4 |
| 7 | 27150106671 | 定位銷 | Shaft | Y | 1 |
| 8 | 4030000065 | 油杯JB7940.1-M10*1 | Grease nipple jb7940.1-m10*1 | Y | 2 |
| 9 | 4041000822 | 直接頭LGB155-01822 | Straight joint lgb155-01822 | Y | 2 |
| 10 | 4011000197 | 螺栓GB5783-M12*25EpZn-8.8 | Bolt gb5783-m12*25epzn-8.8 | Y | 4 |
| 11 | 4011010621 | 螺栓GB5783-M16*45flZnyc-12.9-480 | Bolt gb5783-m16*45flznyc-12.9-480 | Y | 8 |
| 12 | 27150110001 | 轉(zhuǎn)向缸座 | Steering cylinder base | Y | 1 |
| 13 | 27150109951 | 軸套 | Sleeve | Y | 4 |
| 14 | 4120000015 | 黃油嘴保護(hù)帽JXHF-00006 | Butter nozzle cap jxhf-00006 | Y | 2 |
